SIRIO GPA 40-70 Base Antenna 4m 6m

SIRIO GPA 40-70 Base Antenna 4m 6m

  • £40.00
Tax included.


Features: - Base station antenna, Mono-band Omnidirectional, Unity gain Made of aluminium alloy 6063 T-832 Tunable by whip length adjusting Side mast mounting allowed by optional bracket FT-2 code 2510004.00 Part Numbers: P/N 2101401.00 GPA 40-70 Electrical Data Type: 1/4Œ«í‚ ground plane Frequency range: GPA 40-70: tunable 40...70 MHz Impedance: 50Œ«íÖ diation (H-plane): 360ŒçíÊ omnidirectional Radiation (E-plane): beamwidth @ -3 dB = 86ŒçíÊ Radiation angle: 0ŒçíÊ Polarization: linear vertical Gain: 0 dBd - 2.15 dBi Bandwidth @ SWR Œçí‰2: GPA 40-70: Œçí€3.7 MHz @ 40 MHz SWR @ res. freq.: 1.2 @ start freq. GPA 40-70: 1000 Watts Connector: UHF-female Mechanical Data - Materials: Aluminium, Chromed brass, Nylon - Wind load / resistance: GPA 40-70: 85 N at 150 Km/h / 150 Km/h - Wind surface: GPA 40-70: 0.07 mŒ©í‡ - Height (approx.): GPA 40-70: 3200 mm - Weight (approx.): GPA 40-70: 935 gr - Radial length (approx.): GPA 40-70: 1800 mm - Mounting mast: ŒŒÈ 35-40 mm
