Moonraker MICRO II Multi standard CB Transceiver UK 40 EU

Moonraker MICRO II Multi standard CB Transceiver UK 40 EU

A great Micro sized CB radio, complete ready to go with cigar power lead for 12v supply, microphone and bracket all at a budget price!

Specifications

• Modulation Mode: AM/FM

• Frequency Range: 26.330 to 27.99125 MHz (Multistranded)

• Frequency Set: UK 40ch 27.60125 to 27.99125 MHz

• Frequency Control: P.L.L.

• Frequency Tolerance: ±5.0ppm

• Operating Temperature: -20°/+50°C

• DC Input Voltage: 13.2V

• Dimensions: H-104mm × W-108mm × D-25mm

• Weight: 416g

• Antenna Connector: UHF,SO-239

• Current drain Transmit: 2A MAX /Receive: Squelched 0.3A /VOL Max: 0.8A

Transmitter

• Power Output: 4 Watt AM/FM

• Transmission Interference: inferior to 4nW (-54dbm)

• Frequency Response: 300-3000Hz

• Modulation Signal Distortion: inferior to 5% Output

• Impedance: 50 ohms

Receiver

• Sensitivity: Less than 1uV for 10dB(S+N)/N

• Image Rejection: 70dB

• Adjacent Channel Rejection: 60dB

• IF Frequencies: 1st 10.695MHz 2nd 455KHz

• AGC: Less than 10dB change in audio

• Squelch: Output for inputs from 10 to 50000uV /Less than 1uV

• Audio Output Power: 1 Watt

• Frequency Response: 300-3000Hz
