Maas RS 1000 SWR Power Meter

Maas RS 1000 SWR Power Meter

  • £84.95
Tax included.


Standing waves and power meter in a rugged metal housing. The RS-1000 has two separate entrances for different frequency ranges.

Specifications

Frequency range 1.8 - 160 MHz / 430-1300 MHz 1.8 - 160 MHz / 430-1300 MHz Performance 200 / 400 W) to 400 W (switchable 5 W / 20 W / 200 / 400 W) Minimum power for SWR measurement: 0.5W Accuracy @ 5W Range: +/-5% @ 5W Range: + / -5% @ 20W Range: +/-7,5% @ 20W Range: + / -7.5% @ 200W Range: +/-10% @ 200W Range: + / -10% @ 400W Range: +/-12,5% @ 400W Range: + / -12.5% illuminated meter (6.7 x 3.5 cm) can be adjusted (0 adjustment) AVG button Power supply for backlight: 13.8 V DC DC cable included N-female Insertion loss: 0.2 dB (1.8 - 160 MHz) / dB 0.3 (430 - 1300 MHz)

Dimensions (W x H x D in mm) 152 x 68 x 102 (without protruding parts)

Weight 900 g
