CRT CONCORDE I CB Ham Radio AM FM 60w pep

CRT CONCORDE I CB Ham Radio AM FM

SSB 60w pep.

• • AM/FM

  • 28-29.7 mHz

  • AM : 4W (PEP 12W) / 20W (PEP 60W)

  • FM : 4W / 20W / 50W

  • NRC RX/TX adjustable - VOX - CTCSS/DCS

  • FREQUENCY DISPLAY

  • LARGE LCD DISPLAY AND BACKLIT KEYS 7 COLORS :


TX 000950

Norm

AMATEUR RADIO (restriction : in emission use with amator radio certificate obligatory)

Mode

AM / FM

Frequency range

28 - 29.7 mHz

Power

adjustable AM : 4W (PEP 12W) / 20W (PEP 60W) and FM : 4W / 20W / 50W

Input voltage

13.8V DC

Frequency Band

A/B/C/D/E/F/G/H/I + VFO

Channels

40 channels (programmable) in each band

Memories

99

Step of increment

1KHz / 5KHz / 10KHz / 100KHz / 1MHz

ND CH FREQUENCY MODE POWER EXPAND METHOD

HF:24.715-30.105MHz

BAA 40CH 25.615-26.055MHz

AM/FM AM:4W/20W
FM:
4W/20W/50W

Hold【FRQ】+【SET】
when power radio, turn on
channel knob to Band you wish to use
HAM Band. HF Band. CB Band Multi-Norms & UK 40.

PUSH Channel knob in to confirm.

B 40CH 26.065-26.505MHz
C 40CH 26.515-26.955MHz
D 40CH 26.965-27.405MHz
E 40CH 27.415-27.855MHz
F 40CH 27.865-28.305MHz
G 40CH 28.315-28.755MHz
H 40CH 28.765-29.205MHz
I 40CH 29.215-29.655MHz
J 40CH 29.665-30.105MHz
K 40CH 24.715-25.155MHz
L 40CH 25.165-25.605MHz

Cb Multi-Norms & UK 40

S-METER

Yes

SWR METER

Yes : protection with forbidding TX if TOS to high

SQUELCH

Manual or Automatic (ASQ)

ROGER BEEP

Yes : TX beep end (off / 1-6)

RF GAIN

Yes : adjust sensibility on RX

MICRO GAIN

Yes : 9 levels adjustable

CTCSS / DCS (encoder/decoder)

38 CTCSS / 104 DCS : sub-audio code to activate repeater like selective tone

Filters NB/HI CUT

Yes : noise filters

NRC filter function

Yes : RX/TX noise reduction -adjustable 5 levels-

SPLIT/RELAY function

Yes : allows to transmit and receive on two different frequencies in half duplex

DOUBLE WATCH function

Yes

VOX function

Yes : this feature triggers your microphone sound (hands free)

TOT function

Yes : time out timer

SCAN function

Yes : automatic search of busy channels

COMPANDER function

Yes : TX with a clear voice

RESET function

Function DIMMER

Yes : to adjust dimmer/brightness of front panel - 6levels -

Various functions

ECHO on/off (32niveaux) + BEEP (on/off) + Key Lock + Selection FM deviation 4K (Default 2)

Bonus

REC function (recording) + CLOCK SETTINGS (date and time) + ALARM SETTINGS (a programmed alarm) + backlit keys

Mike

Electret type + UP/DOWN selection + 6 pins plug in front panel -Microphone type selection : electret or dynamic

Display

BIG DISPLAYING FREQUENCY and/or channel + BRIGHT function (backlight brightness) + function CONTRAST (LCD contrast adjustable) + 7 colors available

Deliver with

Bracket, hardware kits, fixed microphone, product manual in French and English

Size

169(L) x 159(L) x 48(H)

Weight

1,02kg
