SENHAIX 8800 (BLACK) BLUETOOTH DUAL BAND HANDHELD RADIO WITH AIRBAND RX PLUS MAG MOUNT
Tax included.
SENHAIX 8800 (BLACK) BLUETOOTH DUAL BAND HANDHELD RADIO WITH AIRBAND RX
Standard Accessories
Battery, Antenna, Charger, Adaptor, Belt Clip, Hand Strap
Radio Features
-
Power Output 5W
-
Dual Band
-
Dual Watch
-
Dual Standby
-
LED Flashlight
-
SOS Warning
-
DTMF Tone
-
ANI Code
-
PTT ID
-
FM Radio
-
Encryption
-
1750Hz Tone
-
Customize Channel Names
-
Bluetooth Programming
-
IOS Apstore App is SHX8800
Technical Specifications
General |
||
Frequency Range |
UHF & VHF |
|
Channel Capacity |
128 Channels |
|
Channel Step |
25KHz(Wide Band), 12.5KHz(Narrow Band) |
|
Frequency Stability |
±2.5ppm |
|
Operating Voltage |
7.4V DC ± 20% |
|
Operating Temperature |
-20℃ ~ +60 ℃ |
|
Antenna Impedance |
50Ω |
|
Dimension |
134*60*38mm(with battery pack) |
|
Weight |
270g(with battery pack, antenna) |
|
Transmitter |
||
|
|
Wide Band |
Narrow Band |
Output Power |
5W |
5W |
Modulation Mode |
16KφF3E |
8KφF3E |
Adjacent Channel Power |
≥65dB |
≥60dB |
Singal Noise Ratio |
≤-40dB |
≤-40dB |
Parasitic Harmonic |
≤65dB |
≥60dB |
Spurious Emission |
≤-36dBm |
≤-36dBm |
Audio Response |
300Hz-3KHz |
300Hz-3KHz |
Audio Distortion |
≤5% |
≤5% |
Receiver |
||
|
|
Wide Band |
Narrow Band |
Sensitivity |
-120dBm (20db SINAD) |
-120dBm (20db SINAD) |
Intermodulation |
≥60dB |
≥55dB |
Adjacent Channel Selectivity |
≥60dB |
≥55dB |
Spurious Rejection |
≥60dB |
≥55dB |
Audio Response |
300Hz-3KHz |
300Hz-3KHz |
Signal to Noise Ratio |
≥45dB |
≥40dB |
Audio Distortion |
≤5% |
≤5% |
Audio Output Power |
1W |
1W |
NAGOYA UT-308UV
CERTIFIED ORIGINAL NAGOYA ANTENNA BLACK
SMA FEMALE CONNECTOR & PL259 ADAPTER
DUAL-BAND VHF & UHF (137-174, 400-520 MHZ), WEATHERPROOF, STRONG RARE EARTH MAGNET BASE
EASY TO INSTALL, OMNI-DIRECTIONAL
MEASURES 22 INCHES
STAINLESS STEEL ANTENNA
